1/3 HP Gear Drive Clamp Mount Drum Mixer
$3,363.00
Lead Time: 3-4 Weeks
Description
IMC CMBG gear drive clamp mount drum mixers are ideal for mixing high viscosity materials like heavy paints, resin, and polymers. This model will also help re-suspend any material that may have settled at the bottom of your drum. The clamp design on this model allows it to clamp on to the rim of your drum and have the shaft be inserted into either a closed or open drum. All models come with IMC’s BBO folding blade. TEFC Models include a plug, cord, and switch. Variable speed models include a prewired speed controller and is mounted on the motor. Explosion proof models have motor leads only. Other options are available, contact us for a quote!
Specifications
| IMC Part |
6120334-5000 |
|---|---|
| IMC Model |
IMC-CMBG-02-13-TEFC |
| Track Inventory |
Yes |
| HP |
0.33 |
| Speed Controller |
No |
| Motor Type |
TEFC |
| Frame |
56C |
| Impeller Type |
BBO |
| Impeller Diameter |
7" |
| Impeller Attachment |
Set Screw |
| Impeller Material |
304 SS |
| Number of Impeller |
2 |
| Phase |
1 |
| Mount |
Clamp Mount |
| Mount Dimmension |
Adjustable |
| RPM |
350 |
| Shaft Diameter |
.625" |
| Shaft Length (in) |
32" |
| Shaft Material |
316 SS |
| Voltage |
115/230 V |
| Drive |
Gear |
| Gearbox |
Yes |
| Gear Ratio |
5:1 |
| Gearbox Frame |
Parallel |
